APPLICATIONS
For maintaining the water pressure in a residential water pump system when the pump is not running.
FEATURES & BENEFITS
- ANSI/NSF Standard 61 approved - assures safe, clean drinking water
- Blended butyl rubber diaphragm system - isolates the air charge from the water chamber and provides long tank life
- Heavy-duty steel construction - 16 gauge cold rolled steel with appliance-quality paint
- Steel clench ring protects diaphragm from rubbing against tank wall - eliminates abrasion and reduces condensation
- Brass air valve with O-ring seal - allows adjustment of air pre-charge
Model: |
RL81 |
Gallons: |
81 |
Drawdown @ 30/50 PSI (Gal): |
27.6 |
Fixtures: |
27 |
Type: |
Vertical |
System Connect: |
1 1/4" MPT |
Dimensions: |
21" x 21" x 59.25" |
Warranty: |
5 Years |
